Snap fit capping machine

Snap fit capping machine
Snap fit capping machine
Product Code : NKSC-150PS/250PS/350
Brand Name : NK Industries
Product Description

The series of Automatic Snap fit capping machine is used to apply Snap fit type of closure on Plastic bottle. Snap Fit closure where closure held in place through the use of beads or undercuts rather than threads. Automatic Rotary Snap fit capping machine available in 4 head, 6 head, 8 head and 12 head configuration as per the output requirement.

Technical Specification:

Machine Name

4 head Snap Fit capping machine

6 head Snap Fit capping machine

8 head Snap Fit capping machine

Model

NKSC-150PS

NKSC-250PS

NKSC-350PS

Direction

Left to Right

Left to Right

Left to Right

Production rate

Up to 100 Bottle per minute for 50 ml bottle

Up to 120 Bottle per minute for 50 ml bottle

Up to 180 Bottle per minute for 50 ml bottle

Electrical supply

1 HP for Main Drive
0.25 HP for Orientation Unit

1 HP for Main Drive
0.25 HP for Orientation Unit

2 HP for Main Drive
0.50 HP for Orientation Unit

Type of Capping

Snap Fit type capping

Snap Fit type capping

Snap Fit type capping

Cap heating system

Swiss Make Air heater system

Swiss Make Air heater system

Swiss Make Air heater system

No of Screw Capping Head

4 head

6 Head

8 Head

Auto cap Pick Up ratio

≥99.9%

≥99.9%

≥99.9%

Qualified capping ratio

≥99.8%

≥99.8%

≥99.8%

Power requirement

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

440 V ,3 Phase (4 Wire System ) 50 HZ

Height of Conveyor

Adjustable from 800 to 850 mm

Adjustable from 800 to 850 mm

Adjustable from 800 to 850 mm

Bottle dia

22 mm to 80 mm max

22 mm to 80 mm max

22 mm to 80 mm max

Bottle height

55 mm to 200 mm max

55 mm to 200 mm max

55 mm to 200 mm max

Screw cap dia

22 mm to 52 mm dia cap
(with the help of change part)

22 mm to 52 mm dia cap
(with the help of change part)

22 mm to 52 mm dia cap
(with the help of change part)

Dimension

(L X W X H) mm

1530 x 812 x 1900

1830 x 812 x 1900

2130 X 915 x 1900
